Description
Features
- Built-in illumination via LED or fiber optic technology
- Adjustable brightness levels for varying lighting conditions
- Clear reticle visibility against dark backgrounds
- Compatible with a wide range of rifle scopes
Applications
- Hunting at dawn or dusk
- Tactical and law enforcement operations in low-light environments
- Shooting sports requiring quick target acquisition
- Precision aiming in challenging lighting conditions
Benefits
- Enhances target acquisition and shooting accuracy in low light
- Adjustable illumination adapts to different environments
- Reduces eye strain during prolonged use
- Improves performance in dimly lit scenarios without affecting normal daylight use
Performance
- Maintains reticle clarity and contrast under low-light conditions
- Allows precise aiming even in dark or shadowed areas
- Adjustable settings provide optimal performance across lighting ranges
- Reliable illumination with minimal power consumption
Specifications
Substrate | B270 / N-BK7/ H-K9L / H-K51 |
Dimensional Tolerance | -0.1mm |
Thickness Tolerance | ±0.05mm |
Surface Flatness | 2(1)@632.8nm |
Surface Quality | 20/10 |
Line Width | minimum 0.003mm |
Edges | Ground , 0.3mm max. Full width bevel |
Clear Aperture | 90% |
Parallelism | <45” |
Coating | High optical density opaque chrome,Tabs<0.01%@Visible Wavelength |
Transparent Area, AR R<0.35%@Visible Wavelength | |
Process | Glass Etched and Fill in with Sodium Silicate and Titanium Dioxide |
