Description
Features
- Multi-layer dielectric coating using titanium dioxide (TiO₂) and silicon dioxide (SiO₂)
- Optimized layer thickness and composition for constructive interference
- High reflectivity with minimal light absorption or scattering
- Applied on high-quality glass substrate for durability and stability
Applications
- Dental mirrors for routine and specialized oral examinations
- Enhanced visualization in dentistry for diagnosis and treatment
- Medical optical devices requiring high-contrast reflection
Benefits
- Provides sharp, bright, and accurate images of the oral cavity
- Improves diagnostic precision and treatment effectiveness
- Durable and long-lasting coating for repeated clinical use
- Reduces visual distortion and enhances clinician confidence
Performance
- Multi-layer design ensures maximum reflectivity and minimal scattering
- Maintains optical clarity over time under clinical conditions
- Stable adhesion and consistent performance for professional dental instruments
- Enhances patient examination experience with brighter, clearer reflections
Specifications
| Substrate | B270 |
| Dimensional Tolerance | -0.05mm |
| Thickness Tolerance | ±0.1mm |
| Surface Flatness | 1（0.5）@632.8nm |
| Surface Quality | 40/20 or better |
| Edges | Ground, 0.1-0.2mm. Full width bevel |
| Clear Aperture | 95% |
| Coating | Dielectric Coating, R>99.9%@Visible Wavelength, AOI=38° |
